Lightweight metals have emerged as the go-to choice in a wide range of industries. Metals such as aluminium, titanium and now even magnesium have become vital in automotive, aerospace and many consumer applications. The combination of their abundance, exceptional strength-to-weight ratios and versatility means they are a preferred choice for product engineers all over the world.

Some lightweight alloys offer superior corrosion resistance even when untreated, but it is inevitable that surface treatment will be necessary in a finish product, for performance, longevity and quality purposes. Magnesium is renowned for its poor corrosion resistance - but what is less well know is that some aluminium alloys, such as 2xxx, 7xxx and other high-strength families containing copper or other transition metals are similarly susceptible.

Selecting the right corrosion resistance method is essential to a successful component design and manufacture. Each method has a unique set of advantages and potential issues. We’ve put together this comparison of different treatment methods to help you find the most suitable solution for your needs.

  1. Anodising

The most popular method of improving corrosion resistance on aluminium is anodisation. It, generally speaking, involves a four step process to achieve protection.

The first stage of which involves immersing the material in a bath of conductive solution - typically a low pH acid bath - and connecting the alloy to the anode of an electrical circuit. When an electrical current is applied, an oxidation reaction occurs at the metal surface:

This causes the natural oxide on the surface metal to thicken, creating a protective outer layer of aluminium oxide. The thickness can be altered through extending the coating time, thus offering a versatile range of applications:

  • When applied lightly, it can provide good pretreatment for paint or subsequent coatings
  • Specific colour effects can be achieved when dyed
  • When applied thinly (typically <20μm), it is translucent which preserves the metallic aesthetic, if so desired

The coating thickness decision plays a key role in determining corrosion resistance. In outdoor conditions, or when under intensive indoor stress (such as when under persistent liquid contact), a minimum of 20μm is recommended. Where layers necessitate 10μm thickness, the higher voltage required can damage the material, cracking the protective oxide layer and becoming porous.

Furthermore, the growth mechanism and columnar microstructure caused, through-thickness cracking occurs extensively on corners, limiting edge protection offered by anodising layers. Hot water seals can be used to provide more substantial protection, but more effective seals can be achieved through the use of hazardous chemical solutions such as nickel acetate or sodium dichromate.

Ultimately, for materials that require certain aesthetic qualities whilst remaining highly resistant to corrosion whilst in contact with liquids, anodisation is not the best method of corrosion resistance improvement.

  1. PEO

Plasma Electrolytic Oxidation (PEO) involves the use of plasma discharges to transform the metallic surface of light metals. It forms an adhesive oxide layer that is both hard and dense.

Components are immersed in a bath and an electrical current is used to ‘grow’ a uniform layer of oxide on the surface. PEO occurs over a three stage process:

  1. Oxidation of the substrate (as occurs in the anodising process)
  2. Co-deposition of the elements from the electrolyte into the coating
  3. Modification of the resulting layer by plasma discharge

Want to learn more about Keronite's PEO methodology? Click below to download the free white paper.

PEO forms hard, dense and wear-resistant coatings for lightweight metals such as aluminium, titanium and magnesium. When compared directly to anodised coatings, PEO forms coatings with higher hardness, chemical passivity and an advantageous, irregular pore structure that creates high strain tolerance and stronger adhesion.

Beyond the superior physical and chemical characteristics, the PEO process can be conducted in an environmentally friendly method, due to benign electrolytes available for use and non-toxic byproducts of the oxidation process. Electrolytes are free from acids, ammonia, heavy metals and chromium, whilst the low concentration alkaline solutions used are a low hazard and easily disposed of.

This culminates in a much greener solution than alternatives, as well having a range of other benefits.

  1. Chromate conversion coating

Increasing governmental and regulatory scrutiny of manufacturing processes has lead to the gradual outphasing of chromate conversion coating as a corrosion resistance technique, even though it’s one of the most effective methods.

Chromate conversion chemistries do vary widely, but many include the application of chromic acid, sodium, potassium chromate or dichromate solutions to clean metallic surface along with other additives. The use of such additives causes redox reactions with the surface, leaving a passive film containing chrome (IV) oxide and hydrated compounds on the substrate metal. This provides high corrosion resistance and retains subsequent coatings well.

The high corrosion protection stems from the ability of chromium (VI) compounds to re-form a protective oxide film in a damaged area of coating exposed to atmospheric oxygen. This is referred to as self-healing. A similar mechanism is used to create stainless steel: chromium added to the alloy naturally forms a very thin passive chrome oxide layer on the surface, preventing oxidation of the iron. This quickly reforms if the surface is damaged and subsurface chromium exposed to atmosphere. Chromate can also be used as an addition to paints or as a sealer for anodizing, enhancing their corrosion protection.

Hexavalent chromium compounds, of the sort used used in chromate conversion treatment is now known to have damaging and carcinogenic qualities, however. The byproducts of chromate conversion coatings are highly hazardous and it is therefore of no surprise that a hard line is being taken on materials using this process.

Today, its use is banned in many industries and its use is highly regulated. It is still widely used in the risk-averse aerospace industry but this is coming under increasing pressure to change. Unfortunately, it remains the best chemical passivation treatment for aluminium due to its self healing properties. Intense research began in the 1980’s to find chromium-free self-healing alternatives but these are yet to match its overall protection levels. Engineers are looking to alternatives like anodising or PEO based treatments for improved performance in harsh environments.
